FY-3208Q/3206Q (Spt510/35pl)

Product Description

Infiniti/Challenger/Phaeton Printer FY-3208Q, FY-3206Q



1, Equipped with Seiko SPT510/35pl print head.

2, X,Y axis AC servo motors / bearing rail, stable and long durability.

3, Full aluminum platform, more strong and flat.

4, Individual positive pressure cleaning.





Model

FY-3206Q

FY-3208Q

Print Head

Type

Seiko Spt510 – 35pl

Quantity

6

4 * 2

Resolution (dpi)

1080

Color

6 color

Double 4 color

Speed

Draft

39m2/hr

76m2/hr

Standard

27m2/hr

51m2/hr

Quality

18m2/hr

34m2/hr

Media

Width

Max 3300mm (129.92’)

Type

Frontlit, Backlit, Vinyl, Polyester, Window Film, Mesh, Leather, Backlit Film etc

Weight

Roll media: 80kgs

Thickness

Max 4mm

Feeding and Take-up

Equipped

Cleaning System

Positive Pressure Cleaning, Anti-Clogging Flash Function & Capping System

Heating System

3 way intelligent heater

Clamp

Equipped

Rip Software

Photoprint, Maintop, Wasatch (optional)

Print Head Height

2-6mm (adjustable)

Interface

USB2.0

Power

AC220V, 50HZ/60HZ

Dimension (mm)

Machine

L4500*W905*H1260 mm 362KGS

Packing

L4650*W970*H1550 mm 582KGS
